Mondraker RAZE R RED GREY
Preis UVP | 0,000 |
---|---|
Titel | Mondraker RAZE R RED GREY |
Laufradgröße | 29 Zoll |
Modelljahr | 2023 |
Hersteller | Mondraker |
Rahmen | Raze 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 130mm travel, Forward Geometry, one piece Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpost internal routing, MAX capacity sealed |
Gabel | Fox 36 29 Float GRIP EVOL Rhythm, 150mm, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: sweep adjust compression, low-speed rebound, air preload |
Dämpfer | Fox Float DPS LV EVOL Performance, 205x57.5mm. Settings: rebound, 3-position compression adjustment (Open/Mid/Lock), air preload. Trunnion top mount, 30x8mm bottom bushings |
Dämpfereinstellungen | Light compression, light rebound, air volume spacer 0.6 |
Bremse | Sram G2 R, 4-piston caliper, Centerline VR200mm / HR 180mm IS 6 bolts one-piece rotor, steel-backed organic pads |
Bremshebel | Sram G2 R, tool-free reach adjust |
Schalthebel | Sram Trigger NX Eagle, 12s, X-Actuation 1:1 |
Schaltwerk | Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1 |
Schaltauge | Sram UDH |
Kurbelgarnitur | Truvativ Stylo 7k Eagle, Boost, DUB axle, Direct mount chain ring, S/M size: 170mm, L/XL size: 175mm |
Kette | Sram NX Eagle, 12s, Powerlock |
Kettenblätter | 32T, CNC-machined alloy, X-SYNC 2 |
Kassette | Sram XG-1230, 11-50T, 12s |
Felgen | Mavic CrossMax XL S, 29 Boost 30mm internal width, hookless, tubeless ready, 24 spokes |
Reifen vorn | Maxxis Dissector 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead |
Reifen hinten | Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead |
Vorbau | Onoff Sulfur FG 30mm, 6061 forged alloy, 31.8mm barbore |
Lenker | Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore |
Griffe | Onoff Twin, 1lock-on, 135mm |
Sattel | MDK series PU 2023 |
Sattelstütze | Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm |
Steuersatz | Onoff Saturn tapered for 1-1/8 to 1-1/2 head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º |
Nabe vorn | Infinity hub, Boost 15x110mm, IS 6 bolts |
Nabe hinten | Infinity hub, ID360 freewheel technology, Boost 12x148mm, IS 6 bolts |
Innenlager | Sram DUB BSA, sealed bearings, 73mm |
Pedale | - |
